Q-PANEL SELECTOR
ASPxLabel
This tool helps you select the appropriate Q-PANEL standard substrate(s) for your application. Use the checkboxes to filter on panel categories, and dropdown boxes to specify part numbers, metal, finish, dimensions, and price level. Use the “Add to Cart” button to add selections to your list to send to Q-Lab for a quote. Can’t find what you're looking for? Request a Custom Panel.
| | | | | | | | | | | |
| | | | | | | | | | |
| |
 | Loading… |
|
| Loading… |
| | |
| Loading… |
|
| Loading… |
|
| Loading… |
|
| Loading… |
| | |
| |
| A-23.5 | Type A, 2 × 3.5 × 0.025", 3003 H14 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 500 | 9 | 2.000 | 3.500 | 0.030 | $ |
| |
| A-35 | Type A, 3 × 5 × 0.025", 3003 H14 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 500 | 19 | 3.000 | 5.000 | 0.030 | $$ |
| |
| A-36 | Type A, 3 × 6 × 0.025", 3003 H14 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 500 | 23 | 3.000 | 6.000 | 0.030 | $$ |
| |
| A-46 | Type A, 4 × 6 × 0.025", 3003 H14 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 250 | 16 | 4.000 | 6.000 | 0.030 | $$ |
| |
| A-48 | Type A, 4 × 8 × 0.025", 3003 H14 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 150 | 13 | 4.000 | 8.000 | 0.030 | $$ |
| |
| AD-14-N | Type AD, 1 × 4 × 0.063", 2024 T3 aluminum, Alclad surface, no Q-shaped hole, Q-PANEL Test Substrate
| Aluminum (Alclad) | Mill | 600 | 16 | 1.000 | 4.000 | 0.060 | $$ |
| |
| AL-35 | Type AL, 3 × 5 × 0.025", 3003 H14 aluminum, chromated surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Chromated) | Smooth Mill | 500 | 19 | 3.000 | 5.000 | 0.030 | $$ |
| |
| AL-36 | Type AL, 3 × 6 × 0.025", 3003 H14 aluminum, chromated surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Chromated) | Smooth Mill | 500 | 23 | 3.000 | 6.000 | 0.030 | $$ |
| |
| AQ-24 | Type AQ, 2 × 4 × 0.032", 5005 H24 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 600 | 16 | 2.000 | 4.000 | 0.030 | $ |
| |
| AQ-36 | Type AQ, 3 × 6 × 0.032", 5005 H24 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 400 | 23 | 3.000 | 6.000 | 0.030 | $$ |
| |
| AQ-44 | Type AQ, 4 × 4 × 0.032", 5005 H24 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 200 | 10 | 4.000 | 4.000 | 0.030 | $$ |
| |
| AQ-46 | Type AQ, 4 × 6 × 0.032", 5005 H24 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 300 | 23 | 4.000 | 6.000 | 0.030 | $$ |
| |
| AQ-48 | Type AQ, 4 × 8 × 0.032", 5005 H24 aluminum, bare surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 125 | 13 | 4.000 | 8.000 | 0.030 | $$ |
| |
| AQT-36 | Type AQT, 3 × 6 × 0.032", 5005 H24 aluminum, chromated surface, smooth mill finish, Q-PANEL Test Substrate
| Aluminum (Chromated) | Smooth Mill | 400 | 23 | 3.000 | 6.000 | 0.030 | $$ |
| |
| AR-14-N | Type AR, 1 × 4 × 0.063", aluminum, bare surface, no Q-shaped hole, Q-PANEL Test Substrate
| Aluminum (Bare) | Smooth Mill | 600 | 16 | 1.000 | 4.000 | 0.060 | $$ |
| |
| D-36 | Type D, 3 × 6 × 0.010", 1008/1010 steel, smooth finish, Q-PANEL Test Substrate
| Steel (Bare) | Smooth Mill | 600 | 32 | 3.000 | 6.000 | 0.010 | $ |
| |
| D-46 | Type D, 4 × 6 × 0.010", 1008/1010 steel, smooth finish, Q-PANEL Test Substrate
| Steel (Bare) | Smooth Mill | 400 | 28 | 4.000 | 6.000 | 0.010 | $ |
| |
| QD-23.5 | Type QD, 2 × 3.5 × 0.020", 1008/1010 steel, smooth finish, Q-PANEL Test Substrate
| Steel (Bare) | Smooth Mill | 500 | 21 | 2.000 | 3.500 | 0.020 | $ |
| |
| QD-35 | Type QD, 3 × 5 × 0.020", 1008/1010 steel, smooth finish, Q-PANEL Test Substrate
| Steel (Bare) | Smooth Mill | 400 | 37 | 3.000 | 5.000 | 0.020 | $$ |
| |
| QD-36 | Type QD, 3 × 6 × 0.020", 1008/1010 steel, smooth finish, Q-PANEL Test Substrate
| Steel (Bare) | Smooth Mill | 350 | 38 | 3.000 | 6.000 | 0.020 | $$ |
| |
| Loading… |
|
|
